This is the latest stable build based on stable 2020.2.5 SDK. Any feedback will be much appreciated. Enjoy it!
Make sure to use a NVIDIA Studio driver with version at least 456.38 on Windows. No driver updates are required for macOS 10.13 (CUDA).
This version supports the new NVIDIA Ampere architecture on Windows and Linux. Kepler cards with compute model lower than 3.5 are just supported on macOS.
For CORE improvements please check the following Standalone link.
This is the matching Standalone: OctaneRender™ 2020.2.5.
changes of 2020.2.5-R3 plugin
- R25 builds has been added
changes of 2020.2.5-R2 plugin
- Fix: accept the disabling effectors in scatter object and small update for drawing performance
- Fix: functionless "Include object node" parameter of DIRT node
- Fix: removed the Curvature node from list because that was wrongly added
- multi objects for C4D scatter pen
- Added silentmode activation for commandline.exe and -nogui parameters. It's mostly for avoiding the activation warning dialog with batch rendering
changes of 2020.2.5 plugin
- Fix: wrong direction for Octane lights when "use primitives=ON" with other shapes else of "sphere" and "rectangle"
- fix for "cycle" parameter with C4D gradient under OSL mode
Core fixes which may affects the plugins
- Fixed issue causing some textures to be interpreted differently when using out-of-core.
- Fixed SSS pass which was causing a difference between the main pass and the denoiser output passes.
- Fixed issue with scenes with render layers and alpha channel enabled causing incorrect denoiser output.
- Fixed universal camera diopter rotation to be interpreted as degrees instead of 0-1. (viewtopic.php?f=24&t=77888&p=402830#p402830)
- Fixed broken rotation for 2D transforms.
- Fixed an issue causing a freeze when disabling RTX while tone-mapping was happening.
If you see CUDA errors follow 1,2,3,4.
1- Use NVIDIA STUDIO drivers, not Game Ready versions. If you have stability issues try different drivers, some of them could cause instability issues. Make a clean install while doing this to be sure previous files completely removed.
2- Check GPU frequency. Overclocking would cause instability issues
3- Check PSU. Insufficient power output would cause instability issues
4- Check the free amount of GPU's VRAM and system's RAM while working. Low VRAM will/may cause CUDA errors. Be aware of some generator objects will have different triangle count in Picture Viewer than Live Viewer. It’s like “editor/render” parameter. Just try to use the same value. Also try to optimize your scene for polygon count, even use smaller images. Try to use Octane texture nodes rather than using C4D texture/shaders.
Alternatively, use V4 and Out-of-core(OOC) function. Increase RAM for OOC and It should not exceed physical RAM amount. Check TDR value and increase if it's necessary.
5- If you see C4D crashes without CUDA errors, then send us bugreport.zip, screen-shots and video capture to show process and crash moment. Also please send us a sample scene in a format of C4D or ORBX to let us investigate and test it. Alternatively, try to delete/hide some objects/materials until crash gone away. If you find what's causing crashes, send us a sample scene to let us for investigating and bring a fix or solution.
Thanks for helping the development by your feedbacks! It’s impossible to quickly catch every case without user feedbacks! It’s the same procedure as other companies do like Maxon/etc...
WINDOWS ENTERPRISE BUILD (R15-25)
https://render.otoy.com/customerdownloa ... R3-win.rar
WINDOWS SUBSCRIPTION(Studio) BUILD (R15-25)
https://render.otoy.com/customerdownloa ... R3-win.rar
OSX ENTERPRISE BUILD (R15-25)
https://render.otoy.com/customerdownloa ... Macosx.zip
OSX SUBSCRIPTION(Studio) BUILD (R15-25)
https://render.otoy.com/customerdownloa ... Macosx.zip
DEMO WINDOWS: https://render.otoy.com/plugindownloads ... R2-win.rar
DEMO MACOS: https://render.otoy.com/plugindownloads ... Macosx.zip
Requirements:
-You'll need to update your Cinema 4D to latest versions(R16.050, R17.053, R18.057, R19.053, R20.057, R21.115, S22.118, R23.110). Otherwise, the plugin will not work and not appear in menus.
-Internet connection for activation, be sure that C4D and Octane will not be blocked by the firewall and any antivirus software.
-Nvidia drivers at least Nvidia Studio Drivers(minimum 456.38) and be careful with latest Game Ready drivers which can cause cuda errors. Stay with stable one for you.
-Cuda 9.1 driver for OSX.
ONLINE HELP MANUAL
Use embedded help buttons from Octane nodes and windows
To use OFFLINE version of manual from plugin
Download following package and extract to Cinema4D/plugins/c4doctane/manual
https://render.otoy.com/plugindownloads ... p-html.zip
V3 SAMPLE SCENES SET(make a request if you need any specific sample)
https://render.otoy.com/plugindownloads ... scenes.rar
See this topic for some partial samples: viewtopic.php?f=85&t=53989
CINEMA 4D TUTORIALS SECTION: viewforum.php?f=87
CHANGE LOG: https://docs.otoy.com/#60Change%20log
Installation
First, remove all octane related stuff from plugins and the main folder of Cinema4D.
Extract all files to Cinema4D\plugins\c4dOctane directory.
Also, download manual.zip and extract to c4dOctane directory if it's not available in place.
There are a few files for each one is for different Cinema4D version. Remove all except the file is for your version.
Ex. if you have Cinema4D R18.0, keep only "c4dOctane-r18.cdl64" and delete c4dOctane-r17.cdl64, c4dOctane-r16.cdl64, c4dOctane-r15.cdl64, etc..
Cinema 4D Release 15: c4dOctane-r15.cdl64 or c4doctane_R15_demo.dylib
Cinema 4D Release 16: c4dOctane-r16.cdl64 or c4doctane_R16_demo.dylib
Cinema 4D Release 17: c4dOctane-r17.cdl64 or c4doctane_R17_demo.dylib
Cinema 4D Release 18: c4dOctane-r18.cdl64 or c4doctane_R18_demo.dylib
Cinema 4D Release 19: c4dOctane-r19.cdl64 or c4doctane_R19_demo.dylib
Cinema 4D Release 20: c4dOctane-r20.xdl64 or c4doctane_R20_demo.xlib
Cinema 4D Release 21: c4dOctane-r21.xdl64 or c4doctane_R21_demo.xlib
