OctaneRender® 1.025 instancing preview test build

Postby RayTracey » Tue Jul 17, 2012 10:41 pm

RayTracey Tue Jul 17, 2012 10:41 pm
The OctaneRender™ Team is proud to announce a technology preview of OctaneRender™ standalone with instancing support

New features in this preview build

Instancing

New node types:

  • Geometry group node: combines all the geometry on its inputs.
  • Placement: creates a new instance at a different position, using a transform node.
  • Scatter: creates multiple instances, given a list of transform matrices. A matrix is given as 12 numbers, which are the first three rows of
    the transformation matrix. They are given in row major order.
  • Material mapping node: creates an instance of a mesh with some materials replaced.


You can create light sources with instancing. If scaled, the intensity stays the same, the power changes with the square of the scale
factor. IES lights are oriented according to the instance orientation. If a light source is stretched, the direct light calculation is not fully
correct anymore.


Other new features

  • Falloff node: a texture which depends on the angle of incidence of the viewing ray.
  • Color correction: applies a levels and gamma correction to the input texture.
  • Russian roulette on colored surfaces has been improved.
  • In the cuda device manager, the checkboxes for GPU’s that are not supported are not shown. You can only enable GPU’s with a supported
    compute model.
  • Smoothing works on a per material input pin basis, rather than per material node. A mix material is smooth if either of its input materials is
    smooth (There is still a bug in the updating of mix materials).
  • If you click on the statistics bar below the rendered image, you get a popup with texture counts and memory usage.
  • Octane contains new shading code, so there is a chance that some materials don’t show up correctly.
  • There are minor changes to the OCS reader.

Please keep in mind that this instancing release is more like a technology preview, there is no support for exporters so it is not really useful
for most users yet. Instancing will become much more useful when it is released with the plugins (and later in the standalone version when
we specify an exporter file format).


Download here:

Instancing test scenes:

- Scatter scene
- Sierpinski scene

Windows:
ZIP archives:
- 64-bit32-bit

MacOS X:
- Universal (32-bit and 64-bit)

Linux:
- 64-bit

Known issues

  • Due to specific code required to support instancing, the rendering performance of this preview build is about 10-12% slower than the 2.58, even in scenes that don't use instancing.
  • There is a random bug which causes light patterns and intensity to look incorrect about 1/5th of the time. Reloading the scene works in most cases.

Driver Requirements: This release was built with CUDA 4.0(http://www.nvidia.com/page/drivers.html).
For Linux and Mac OS you also need to install the CUDA Toolkit 4.0 (http://developer.nvidia.com/cuda-toolkit-40).
For Mac OS you also need the latest CUDA 4.0 driver (http://www.nvidia.com/object/mac-driver-archive.html).

All builds support only Tesla and Fermi cards (compute model 1.0 to 2.1).
Kepler GPUs are not supported at the moment but a fully functional build is being developed.


Yours,
The OctaneRender™ Team.
RayTracey
OctaneRender Team
OctaneRender Team

Posts: 377
Joined: Sat Jan 16, 2010 10:58 pm
Location: Auckland, New Zealand

Re: OctaneRender® 1.025 instancing preview test build

Postby steveps3 » Wed Jul 18, 2012 6:39 am

steveps3 Wed Jul 18, 2012 6:39 am
I've not downloaded yet but hopefully there is plenty of documentation to go with this. I'm a bit of a country bumpkin and I need things to be explained to me. I am really looking forward to this build though.
(HW) Intel i7 2600k, 16GB DDR3, MSI 560GTX ti (2GB) x 3
(SW) Octane (1.50) Blender (2.70) (exporter 2.02)
(OS) Windows 7(64)
User avatar
steveps3
Licensed Customer
Licensed Customer

Posts: 1118
Joined: Sat Aug 21, 2010 4:07 pm
Location: England

Re: OctaneRender® 1.025 instancing preview test build

Postby bepeg4d » Wed Jul 18, 2012 6:50 am

bepeg4d Wed Jul 18, 2012 6:50 am
well done guys, things are getting better and better :D
ciao beppe
User avatar
bepeg4d
Octane Guru
Octane Guru

Posts: 6891
Joined: Wed Jun 02, 2010 6:02 am
Location: Italy

Re: OctaneRender® 1.025 instancing preview test build

Postby necko77 » Wed Jul 18, 2012 6:53 am

necko77 Wed Jul 18, 2012 6:53 am
thank you dear coders :)

i will check this out as soon as i came back from work...


thx
ArchiCad, Blender, Moi3d
GTX 580 3GB
Win 7, 64 Bit
User avatar
necko77

Posts: 323
Joined: Thu Jan 21, 2010 11:27 am
Location: Bosnia&Hercegovina

Re: OctaneRender® 1.025 instancing preview test build

Postby justix » Wed Jul 18, 2012 8:28 am

justix Wed Jul 18, 2012 8:28 am
Scatter benchmark as it is (pmc 1000maxsamples)

5.03min on my GTX470 2Gb

and different camera angle in DL 1:03

..not bad considering my spec is quite dated....
Attachments
Direct Light 1:47
PMC 5:03
Win 7 64 | 2 X MSI AERO GtX 1070| Intel I7-6850K| 32 GB DDR4 RAM | Asus X99 II-A
User avatar
justix
Licensed Customer
Licensed Customer

Posts: 565
Joined: Sat Feb 27, 2010 8:01 pm

Re: OctaneRender® 1.025 instancing preview test build

Postby tonycho » Wed Jul 18, 2012 8:42 am

tonycho Wed Jul 18, 2012 8:42 am
Thanks Otoy Team
Will download soon :D
http://www.antoni3D.com
Win 7 64 |GTX 680 4 Gb (Display) | 3 x GTX690 4Gb | Intel i5 |Corsair 16GB
User avatar
tonycho
Licensed Customer
Licensed Customer

Posts: 391
Joined: Mon Jun 07, 2010 3:03 am
Location: Surabaya - Indonesia

Re: OctaneRender® 1.025 instancing preview test build

Postby gabrielefx » Wed Jul 18, 2012 8:46 am

gabrielefx Wed Jul 18, 2012 8:46 am
I love you...
Attachments
quad Titan Kepler 6GB + quad Titan X Pascal 12GB + quad GTX1080 8GB + dual GTX1080Ti 11GB
User avatar
gabrielefx
Licensed Customer
Licensed Customer

Posts: 1701
Joined: Wed Sep 28, 2011 2:00 pm

Re: OctaneRender® 1.025 instancing preview test build

Postby Q-Games » Wed Jul 18, 2012 9:12 am

Q-Games Wed Jul 18, 2012 9:12 am
Great news! I'm gonna check it out now, thanks guys! ;)
Intel Core i7-2600 CPU @ 3.40GHz | RAM 16GB DDR3 | GeForce GTX 480 Core 405 MHz | Win7 64bit Jap
User avatar
Q-Games
Licensed Customer
Licensed Customer

Posts: 94
Joined: Wed Sep 07, 2011 8:56 am
Location: Japan

Re: OctaneRender® 1.025 instancing preview test build

Postby tyrot » Wed Jul 18, 2012 9:15 am

tyrot Wed Jul 18, 2012 9:15 am
oh man - after waiting countless days...weeks...
here we go...

THANK YOU Octane team and OTOY- you kept your promise!
..
tyrot
Licensed Customer
Licensed Customer

Posts: 138
Joined: Sun Dec 19, 2010 8:43 am

Re: OctaneRender® 1.025 instancing preview test build

Postby Q-Games » Wed Jul 18, 2012 9:33 am

Q-Games Wed Jul 18, 2012 9:33 am
A video tutorial on how the two sample scenes were made would be appreciate. ;)
Intel Core i7-2600 CPU @ 3.40GHz | RAM 16GB DDR3 | GeForce GTX 480 Core 405 MHz | Win7 64bit Jap
User avatar
Q-Games
Licensed Customer
Licensed Customer

Posts: 94
Joined: Wed Sep 07, 2011 8:56 am
Location: Japan
