OctaneRender® for ArchiCAD beta - build 1.02b [OBSOLETE]

[face_off]

This is the recommended thread for downloading, and posting any questions, suggestions or support queries for OctaneRender for ArchiCAD, build 1.02b (TEST RELEASE). This version is compiled against Octane 1.02, so see the requirements for that build regarding compatibility with your video card.

If you have a support issue, pls provide the following information:
- Operating System (ie. Win XP, Vista, 7, 8)
- 32 or 64 bit
- Amount of RAM
- Graphics Card(s) - model (ie. GTX 580, 3GB)
- Nvidia driver version
- ArchiCAD version (ArchiCAD -> Help -> License Information -> Version and Build Number
- OctaneRender for ArchiCAD version (ie. 1.02a)
- In the unlikely event of a crash, pls provide the dump report from the C:\Users\[username]\Graphisoft\BugReporting-[version] folder (on Win 7). Either post or email (to "paul at physicalc-consulting.com") the "ArchiCAD-XXXXXX-FATAL.RPT" file from this folder.

Change Log from release 1.02a
- Fixed issue where using the "Set lighting to Daylight" option was not setting the sun vector correctly
- Fixed issue where ArchiCAD material texture scales were not translating to Octane material texture scales
- When using "Set lighting to Image Based Lighting", the previous image "power" is now used (in addition to the texture)

For more information...
- Read the manual
- Read the FAQ
- Watch the Introductory Tutorial Video
- Check the Facebook page
- Post your question on this forum thread

Troubleshooting
- GUI issues (lock-up/crash) on large scenes (ie. 4million polys) - potentially due to the Windows Vista/7 "Timeout Detection and Recovery" http://msdn.microsoft.com/en-us/library ... 87368.aspx. Settings can be changed using Regedit. The recommended setting for Octane are registry setting HKLM\System\CurrentControlSet\Control\GraphicsDrivers, TdrLevel = 3, TdrDelay =10 (if these settings are not already there, rightclick the right panel -> New -> DWORD). You will need to reboot after changing these settings.

Limitations
- materials selection (to auto-populate the "Select from Selection" combo box on the Materials tab of the plug, does not work unless you are viewing a 3d perspective window.
- Changing an element's material will not automatically select the new material in the Materials tab of the plugin. You will need to select another element, and then re-select the original element to get the "Select from Selection" combo box to populate the new material
- To use the material picker (Materials Tab -> "Select from Selection") on Curtain Wall objects, put the Curtain Wall in edit mode
- The ArchiCAD Perspective camera roll angle is not transposed to the Octane thinlens "up" pin. If you need to rotate the render, manually adjust the "up" vector.
- Image map rotation is not current supported by OctaneRender, so any rotation of texturemaps in ArchiCAD materials is ignored in the texture conversion to Octane.
- GDL materials of the same name, for different objects, are merged to be one Octane material
- On ArchiCAD 14, selecting from the "Select from Selection" popup is disabled (ie. you cannot choose from the materials of the currently selected scene element). Instead, you will need to select materials in the plugin Materials tab via the "Select from Materials" popup.
- On ArchiCAD 14, when doing a photorender, sun study or flythrough, the render viewport may not display the render as it progresses. This is a GUI display issue, and the render is working as per normal

Download Links
Download the plugin from the following links:
- OctaneRender for ArchiCAD 14 1.02b beta (32 & 64 bit)
- OctaneRender for ArchiCAD 15 1.02b beta (32 & 64 bit)
- OctaneRender for ArchiCAD 16 1.02b beta (32 & 64 bit)

Paul

[EAHP74]

Hi Paul,
Good job....
À small render with the last version 1.02b
Cordiales,
Elie

[face_off]

Nice Elie. I like the focal point being towards the back of the scene - great effect.

Paul

[face_off]

I have posted a new TEST version. Pls see the new thread for release 1.11b.

Paul
